ApexPlatinum Digital True Color

ApexPlatinum Digital True Color Welding Lens

Clarity Perfected. Control Unmatched.

The ApexPlatinum Digital True Color lens is the next step in precision welding optics—engineered for welders who want the most natural, accurate view of the arc possible. Built on the same proven platform as our flagship digital lenses, this model replaces the blue filter and puddle with a platinum true-color filter, delivering unmatched color realism and visual balance.

Designed to show the weld exactly as it is, ApexPlatinum enhances contrast without distortion, allowing you to read the puddle, edges, and heat input with confidence. The upgraded arc sensors improve TIG responsiveness, while next-generation construction ensures durability in demanding jobsite conditions.

Now 3mm thinner than previous generations, ApexPlatinum maintains a sleek, low-profile fit without sacrificing strength. A fully digital control system eliminates traditional dials entirely, offering smooth, precise shade adjustment from DIN 8–13 for consistent performance across all processes.

The platinum coating reduces glare and harsh reflections while preserving true color accuracy, depth perception, and superior UV/IR protection—keeping your eyes comfortable and focused through long weld sessions.

When accuracy matters and color truth makes the difference, ApexPlatinum delivers a clearer, calmer, more controlled view of the arc.

True color. Digital precision. Platinum standard.

Specifications:

• Shade: 8–13

• Warranty: 1 Year

• Optical Rating: 1/1/1/2

• Viewing Window: 1 3/8" x 3 11/16"

• Thickness: 6mm

• Eye Protection: UV/IR up to Shade 16

• Sensitivity: Adjustable from Low to High

• Dark to Light Delay: Adjustable from Short to Long

• Power Supply: Solar Cells + 2 Lithium CR1025 Batteries

• Switching Speed: 0.2 milliseconds (Completely Automatic)

• Sensors: Two Independent Wide-Range Arc Sensors

• Certifications: Meets Z87.1 and CE 379

Note: This lens fits most standard 2" x 4" welding helmets. Some hoods or aftermarket flip-fronts may require a slight manual adjustment to fit the lens properly.
